AT Machinery, a specialist with decades of experience in both metal forming and plastic extrusion, offers the high-performance Steel Pipe PVC Coated Making Machine. Designed for precision and high-speed production, our equipment provides a seamless anti-corrosive coating for round steel pipes used in construction, automotive, and industrial fluid systems. We provide fully customizable turn-key solutions to optimize your production efficiency. Contact our engineering team today for a custom layout and factory-direct pricing!
Parameter | Value |
Manufacturer | Yuyao At Machinery Co., Ltd |
Product Name | Steel Pipe PVC Coated Machine |
Processed Material | PE, PVC |
Application | Pipe, Fence, Conduit, Cable Protection |
Extruder Type | Single-Screw |
Screw Diameter | 65 mm |
Screw L/D Ratio | 28:1 |
Screw Material | 38CrMoALA |
Screw Speed | 270 rpm |
Voltage | 220V / 380V / 415V / 440V |
Main Power | 18.5 kW (Total Power: 26 kW) |
Automation | Automatic |
Inverter Brand | Taiwan Shihlin |
Dimensions (LWH) | 9m * 1.6m * 2.5m |
Weight | 1200 KG |
Core Components | PLC, Motor, Bearing, Gearbox, Screw |
Warranty | Over 5 Years |
After-Sales | Overseas Engineer Service Available |
Origin | Zhejiang, China |
By leveraging our dual expertise in metal and plastic, this machine ensures 100% adhesion between the steel pipe and the coating, preventing peeling or air bubbles and extending the pipe's service life in harsh environments.
Our specially engineered die head ensures perfectly uniform thickness around the entire circumference of the pipe, reducing raw material waste by up to 15% and ensuring a flawless aesthetic finish.
The system pre-treats the steel pipe surface to the optimal temperature before extrusion, guaranteeing a thermal bond that resists extreme temperature fluctuations and mechanical stress.
The entire line—from feeding to extrusion to cooling—is managed via a centralized Siemens PLC system, minimizing manual labor costs and reducing the risk of human error during high-speed runs.
Our high-efficiency cooling system stabilizes the coating instantly without deforming the metal core, allowing for higher production speeds while maintaining strict dimensional tolerances.
Production of PVC-coated scaffolding, outdoor railings, and fence posts that require high weather resistance and rust prevention.
Manufacturing of structural tubes and fluid lines that need protection against abrasion, salt, and chemicals.
Anti-corrosive piping for chemical plants or underground water transport where bare steel would fail prematurely.
Producing heavy-duty plastic-coated metal conduits for wire protection in high-security or hazardous industrial zones.
While our standard system is optimized for round pipes, AT Machinery provides custom-engineered die heads and rollers. We can tailor the equipment to coat square, rectangular, or oval profiles based on your specific project requirements.
Adhesion is critical. Our integrated induction pre-heating system ensures the metal surface reaches the perfect temperature for molecular bonding with the PVC. This process eliminates air bubbles and guarantees a permanent bond that resists extreme environmental stress.
A standard customized extrusion line typically takes 45 to 60 days for manufacturing and rigorous factory testing. We provide regular project updates and milestones to ensure your production schedule remains on track.
Yes, we offer comprehensive global support. Our services include on-site installation, hands-on staff training, and technical guidance. For faster setup, we also provide high-definition video commissioning and 24/7 remote technical assistance.
Our high-torque single-screw design is engineered to process both virgin resins and high-quality recycled PVC granules. This flexibility allows you to reduce material costs while maintaining a high-quality, smooth surface finish on your final products.
➩ABOUT US
Yuyao At Machinery Co.,Ltd as a professional manufacturer is mainly engaged in the manufacture of plastic extrusion machinery &metal hose forming machinery. We can provide specialized and tailor-made machines for domestic and overseas markets.With the principle of high-quality products and best service, we always be creative and make our effort to provide good quality machines for customers.The main products of our company are flexible metal conduit machine, flexible shower hose machine,stainless steel flexible corrugated gas hose machine;stainless steel flexible sprinkler hose machine,flexible metal hose PVC coating machine, Steel pipe PE/PVC coating Machine, plastic extrusion machine etc. Welcome to inquire us and hope to build a successful cooperative relationship.
