Our PVC cover conductor production line integrates advanced extrusion technology and precise control systems, ensuring consistent coating quality and high production efficiency. Yuyao At Machinery Co., Ltd., a trusted manufacturer of plastic extrusion machinery, provides customized PVC cover conductor extrusion machine solutions for industrial manufacturers engaged in electrical and construction material production.
Our PVC covered copper conductor tape making machine adopts a precision extrusion die and temperature control system, ensuring uniform PVC coating thickness and strong adhesion between the PVC layer and copper tape. There are no bubbles, cracks or peeling issues, guaranteeing excellent insulation performance.
Equipped with a high-performance extruder and automatic tension control system, the machine achieves continuous and stable production at adjustable speeds. This ensures consistent product quality and high output, meeting the demands of large-scale manufacturing.
The machine can process copper conductor tapes of various widths and thicknesses, and is also compatible with other metal conductor tapes such as aluminum and brass. It can produce different specifications of PVC covered conductor tapes to adapt to diverse application scenarios.
The optimized transmission system and energy-efficient motor reduce power consumption significantly. The machine is also equipped with an exhaust gas treatment device to collect and process volatile organic compounds, complying with global environmental protection standards.
The machine features an intuitive touch screen control panel, allowing operators to easily set and monitor production parameters. It also has multiple safety protection devices to ensure safe and reliable operation.
Copper Conductor Tape PVC Coated Machine | AT-CC-65 | AT-CC-90 | AT-CC-120 |
Extruder screw diameter | Φ65mm | Φ90mm | Φ120mm |
Copper tape width | 10-50mm | 20-80mm | 30-120mm |
Copper tape thickness | 0.1-1.0mm | 0.2-1.5mm | 0.3-2.0mm |
PVC coating thickness | 0.2-1.5mm | 0.3-2.0mm | 0.4-2.5mm |
Production speed | 5-30m/min | 8-40m/min | 10-50m/min |
Maximum line speed | 35m/min | 45m/min | 55m/min |
Total machine power | 15kW | 22kW | 30kW |
Machine size (L×W×H) | 3500×1200×1800mm | 4200×1500×2000mm | 5000×1800×2200mm |
Flat PVC covered copper lightning conductor tape making machine is widely used in the production of electrical and construction materials. The PVC covered copper conductor tapes produced are mainly applied in lightning protection and grounding systems of buildings, power transmission and distribution systems, communication base stations, industrial equipment grounding and railway signal systems. These products have excellent insulation, corrosion resistance and weather resistance, ensuring long-term reliable performance in various harsh environments.
Yuyao At Machinery Co., Ltd. specializes in the research, development and manufacturing of plastic extrusion machinery for over a decade. We have a modern production base and advanced processing equipment, enabling us to deliver high-quality machines on time. We provide turnkey solutions for PVC cover conductor production lines, including factory layout design, equipment manufacturing and integration, on-site installation and commissioning, and professional operator training. We also offer 12-month warranty and lifelong after-sales service, ensuring uninterrupted production for our customers.
Absolutely. Our flat PVC covered copper lightning conductor tape making machine is specifically designed for this application, and the products meet international lightning protection industry standards.
We provide a 12-month comprehensive warranty for the whole machine. During the warranty period, we will replace defective parts free of charge and provide remote technical support.
Yes, we can customize the extruder specification, coating thickness range, production speed and other parameters based on your product specifications and production capacity needs.
Yes, we maintain a large inventory of common spare parts and can deliver them to you quickly to minimize production downtime. We also provide lifelong spare parts supply at reasonable prices.
